特點   Characteristic: ◎整機采用伺服，PLC控制，輸單換單速度快，定位正確，操作畫面簡單易學。 ◎氣動抬落刀線，手動和自動兩種磨刀方式；自動化程度高，省工省時。 ◎電器采用國內外知名品牌，性能穩定。 ◎分切刀采用鎢鋼合金刀片，使用壽命長，分切紙板切口整齊，無壓痕，無毛刺。 ◎壓線采用預壓和精壓相結合，不爆線，易于折彎，線型美觀。 ◎傳動部分采用進口同步帶，傳動平穩，運行噪聲低。 ◎機械定位采用直線導軌和滾珠絲杠相結合，正確度高。 ◎換單時間為20-60秒。

◎Pneumatic up and down the blade and scorer, Auto and manual two methods of grinding knife, high degree of automation, save labor and time.

◎Electric elements adopts international famous brand, ?stable and reliable performance.

◎Slitting blade adopts tungsten alloy blade, long working life, the slitting edge is neat, no press mark, no  burr.

◎Creaser include pre-creaser and fine-creser,  no Seam Broken, easy to bend, Forming beautiful creasing line.

◎Transmission adopts imported synchronous belt, steady, low noise.

◎Machine positioning adopts linear guideway and ballscrew structure, high Precision.

◎Change order time20-60s.

技術參數 Specification:

本機簡介:

本機采用前壓線送紙,后雙膠軸牽紙，采用電動調整刀距,氣動自動鎖緊，采用優質鎢鋼合金刀片,采用五點壓線，采用自動和手動兩種氣動磨刀方式,邊磨刀邊工作。

Brief introduction:

    The machine adopts the front creaser for guiding carton board and double-rubber roller for leading carton board. Cutter blade distance is adjusted electricly.Pneumatic locked, high-quality tungsten steel alloyed cutter blade.the blade can be sharpened both automaticly and manually when the machine is working.

技術參數 Specification:
